GRACO are supplies a wide range of products for Coating, Finishing, Painting, Lubrication, Process, Sealant and Adhesives
Pumps
GRACOare supplies wide range of pumps as following name Husky Air-Operated Double Diaphragm Pump, Glutton 4:1, Husky 716, Dura-Flo and Xtreme, Husky 515, Husky 1040, Falcon 10:1 and Falcon 20:1, High-Flo 4 & High-Flo Plus, Monark 1.5:1, 2:1, President 3:1, 4:1, Orion, Senator 13:1,17:1 & 25:1, Ball Piston Pumps, GRACO Pumps Accessories.
Husky Air operated double diaphragm Pumps
Husky Air-Operated Double Diaphragm Pumps are for unloading above or below ground tanks of any size. They are available in wide range of materials of construction in size including 1/4 in, 3/8 in, 1/2 in, 3/4 in, 1 in, 1-1/2 in, 2 in and 3 in.
Model Overview
| Model |
HUSKY 205 |
HUSKY 307 |
HUSKY 515 |
HUSKY 716 |
| Connection Size |
1/4 in (6.3 mm) |
3/8 in (9.4 mm) |
1/2 in (12.7 mm) or
3/4 in (19.1 mm) |
3/4 in (19.1 mm) |
| Maximum Flow Rate |
5 gpm
(19 lpm) |
7 gpm
(26 lpm) |
15 gpm
(57 lpm) |
16 gpm
(61 lpm) |
| Materials of Construction Available |
Polypropylene,
Kynar (PVDF),
Acetal |
Polypropylene,
Acetal |
Polypropylene,
Kynar (PVDF),
Acetal |
Aluminium
316 Stainless Steel |
| |
 |
 |
 |
 |
| |
| Model |
HUSKY 1040 |
HUSKY 1590 |
HUSKY 2150 |
HUSKY 3275 |
| Connection Size |
1 in (25.4 mm) |
1-1/2 in (38.1 mm) |
2 in (50.8 mm) |
3 in (76.2 mm) |
| Maximum Flow Rate |
40 gpm
(151 lpm) |
100 gpm
(379 lpm) |
150 gpm
(568 lpm) |
275 gpm
(1041 lpm) |
| Materials of Construction Available |
Polypropylene,
Kynar (PVDF),
Acetal |
Polypropylene,
Kynar (PVDF),
Aluminium
316 Stainless Steel |
Polypropylene,
Kynar (PVDF),
Aluminium
316 Stainless Steel,
Ductile Iron |
Aluminium |
| |
 |
 |
 |
 |
Transfer Pumps
Air Power Pump for High Reliability
Piston Pumps
Features and Benefits
- Flow rates up to 5gpm
- Stainless steel and carbon steel options
- Drum length versions have inlet immersed in material for quicker priming of heavier fluid
- Immersed inlets hold prime better than non-immersed
- Available with optional stubby and drum length models
- Air-powered for high reliablility and low cost
Husky Transfer Pumps
Features and Benefits
- Excellent for abrasive, low to medium viscosity fluids and shear sensitive materials
- Suction tube is immersed inside the drum – not the pump
- Quick-priming and immediate flow of product
- Handles fluid viscosities up to 5,000 cps and solids up to 0.09 in (2.29 mm)
- Runs dry without damaging the pump
- Provides air tight seal for moisture-sensitive fluids
Hydra-Clean Pumps
On-Demand High Pressure Cleaning Pumps
Graco Hydra-Clean heavy duty pressure washers support multiple guns and perfect for use in a plant cleaning application.
Features and Benefits
- Versatility in variable pressure, flow and chemical injection provides best cleaning action
- Some models available with chemical injectors
- Configurations available to fit most in plant application requirments
- On demand supply pump stops when valve is closed and runs when valve open
- Does not require an automatic shut off when not in use
55 Gallon Drum Transfer and Supply
Pump from your 55 gallon drums with ease with one of two styles of pumps – double diaphragm orpiston evacuation. They offer flow rates up to 12 gpm, and are available in several materials of construction including: aluminum, carbon steel, stainless steel, polypropylene and acetal.
Spray Guns
GRACO Spray Guns are designed to deliver excellent spray quality in a wide variety of finishing application and painting application
- AA Series G15
- AA Series G40
- AirPro
- XT Series
- Finex
- AL Series
- XTR-R
Electrostatic Air Spray Guns
GRACO Electrostatic Guns are available as following series.
- PRO Xs2
- PRO Xs3
- PRO Xs4
- PRO Xs4 AA
- PRO Auto Xs AA
Accessories
GRACO Accessories parts such as a Pump Repair kit, parts for Spray Guns, Filter, Regulator, Piping process etc.
When it comes to chemical, sanitary and ink applications, it’s tough to beat these Graco pumps! Our process equipment offers a variety of priming piston and air-operated double diaphragm pumps for low to high viscosity fluids and are built for years of reliable service.
 |
Air-Operated Double-Diaphragm Pumps and Packages
Husky standard, abrasion resistant and corrosion resistant double-diaphragm pumps.
|
 |
Air-Operated Piston Transfer Pumps and Packages
Graco Bulldog, Monarks and Senator piston transfer pumps.
|
 |
Ink and Printing Pumps
Air-operated double-diaphragm and piston pumps for pail, drum or bulk tank applications.
|
 |
Cleaning Packages
High-pressure cleaning packages for industrial and sanitary applications.
|
 |
Accessories
Miscellaneous accessories for Graco double-diaphragm and piston pumps.
|
Air-Operated Double-Diaphragm Pumps and Packages
Industrial Diaphragm Pumps
- Husky 1040
- Husky 1050
- Husky 1590
- Husky 205
- Husky 2150
- Husky 307
- Husky 3275
- Husky 515
- Husky 716
Sanitary – Drum & Bin Unloaders
- SaniForce 2150 Drum Unloader
- SaniForce 3150 BES
- SaniForce 3150 HS Drum Unloader
Sanitary – FDA-Compliant Pumps
- SaniForce 1590
- SaniForce 2150
Sanitary – High Sanitation Pumps
- SaniForce 1590 3A
- SaniForce 1590 HS
- SaniForce 3150 3A
- SaniForce 3150 HS
- SaniForce Meat Pump
Air-Operated Piston Transfer Pumps and Packages
Drum & Bin Unloaders
- SaniForce 5:1 Drum Unloader
- SaniForce 6:1 Drum Unloader
Sanitary Piston Pumps
- SaniForce 12:1 Piston Pump
- SaniForce 5:1 Piston Pump
- SaniForce 6:1 Piston Pump
Ink and Printing Pumps
Sanitary
- EPDM Overmolded Diaphragm
- PTFE Overmolded Diaphragm
