| Type |
AW-200PT |
AW-350PT |
AW-600PT |
AW-1000PT |
AW-1500PT |
| Cooling capacity(W) |
1,530/1,800 |
2,940/3,460 |
5,100/6,000 |
8,500/10,000 |
12,700/15,000 |
| Power |
3-phase AC 220V, 50 / 60Hz, when using Trans, can support 380V / 440V Available |
3 phase AC 380V/440V optional, 50/60Hz |
| Dimension(WxDxH)(mm) |
565x400x500(575)
(Including wheel) |
470x600x1010
(Including wheel) |
1100x700x1360
(Including wheel) |
1100x650x1380
(Including wheel) |
1340x650x1544 |
| Compressor |
3 phase, rotary, 800W |
3 phase, rotary, 1100W |
3 phase, rotary, 2600W |
3 phase, Scroll, 3500W |
3 phase, Scroll, 5700W
(Including wheel) |
| Evaporator |
Selectable SUS Coil, Fin tube, Plate Type |
| Condenser |
Air-cooling type, Fin Tube Type |
| Fan Motor |
Ø300, 80W x 1 |
Ø300, 120W x 1 |
Ø350, 180W x 1 |
Ø400, 160W x 2 |
Ø400, 160W x 2 |
| Refrigerant type |
R-410A |
| Use range (ambient temp.) |
5 ~ 45˚C |
| Use range (absorption temp.) |
5 ~ 45˚C |
| Max. pressure of oil |
8 bar |
| Power capacity |
4A/1.5 KVA at 220V/60Hz |
6.3A/2.4 KVA at 220V/60Hz |
5.0A/3.8 KVA at 440V/60Hz |
9.7A/7.5 KVA at 440V/60Hz |
13A/10 KVA at 440V/60Hz |
| Circuit breaker capacity (A) |
10 |
10 |
15 |
20 |
20 |
